The CD-6010 offers top-of-the-line CD playback for any scenario. Designed with the Broadcast market in mind, this CD-player utilizes a tray-loading design, safety features and an emergency release function to accommodate all situations. By employing the CD-5010B drive, rated highly among audiophiles, the CD-6010 offers high-quality sound that is rarely matched in rack-mounted players. With CD’s still so widely used in the Broadcast, Installation, and Touring markets, the CD-6010 is specified.

Another unique feature of the CD-6010 is a monitoring speaker on the front of the unit – perfect for cuing-up tracks straight from the unit if installed in a remote area or closet. The CD-6010 also has 20 points of cue memory, 20 tracks of flash start, and supports Auto Cue, Auto Ready and Incremental Play. Furthermore, it features ±16% pitch control for CD playback speed and up to 100 discs of program memory.

A complete compliment of interface ports are found on the rear panel. Both XLR balanced outputs and RCA unbalanced analogue outputs are provided, as well as SPDIF and AES/EBU digital outputs. The CD-6010 can be controlled through RS-232C, parallel control, or an optional RC-3F footswitch.

With its variety of ease-of-use, safety and bonus features, the CD-6010 is a prime 2U rack-mountable CD player for any professional application.

Features at a glance

  • Highly reliable tray CD player for broadcast, installation or touring applications
  • Audio CD-R/RW, MP3 (192 KBit/s) and WAV playback
  • Flash start capability for up to 20 tracks
  • Numeric keys for track selection and flash start
  • Frame accurate search
  • Memory for up to 20 cue points
  • Skip back function (jump back a few seconds during playback)
  • Auto cue, auto ready, incremental playback, intro check functions
  • Resume function
  • Index search for audio CDs
  • Directory search for MP3 CDs
  • Playback modes include Single, All and Program (up to 99 tracks)
  • Memory for playback programs of up to 100 CDs
  • Repeat modes include Single, All and A–B
  • Selectable interval time between tracks
  • ±16% pitch control
  • Key original function (change speed only)
  • Fade in/out (up to 10 seconds, in 0.5-second steps)
  • Time display (track elapsed / track remain / total remain)
  • Power-on play (timer function)
  • Relay play with multiple units
  • Fader start / event start
  • Lock function to avoid accidental operation
  • Anti-shock memory
  • XLR balanced analogue output (output level may be customized by technical support)
  • RCA unbalanced analogue output
  • Coaxial digital output (SPDIF)
  • XLR AES/EBU digital output
  • Mono output
  • Serial control (RS-232C, D-sub 9-pin)
  • Parallel control port (D-sub 15-pin)
  • Headphones output with dedicated volume control
  • Switchable monitor loudspeaker
  • Last mode memory (Playback mode / Program / Repeat mode / Time display)
  • End Of Message notification
  • Backlit LC display
  • Removable power cable
  • Rack-mountable chassis (2 U)
  • Wireless remote control included (receiver can be disabled if required)
  • Available as options:
    • Footswitch for several functions (RC-3F)
    • Direct play remote control (RC-20)
    • Flash start remote control for instant access to 20 tracks, announcements or effects (RC-SS20)

Specifications

Media and formats
Device type CD player
Compatible discs Compact discs (12cm/8cm, including CD-R discs)
Playable disc types CD-A, CD-ROM (ISO9660 LEVEL 1/2/JOLIET format)
Playable file formats Audio CD (CD-DA), MP3 (MPEG Audio Layer III), WAV
MP3 playback specifications
  Audio Modes stereo/mono
  Sampling Frequency 32 kHz/44.1 kHz/48 kHz
  Bit Rate 32 kbps–320 kbps and VBR
WAV playback specifications
  Sampling Frequency 32 kHz/44.1 kHz/48 kHz
  Sampling Bit Rate 16 bit
Audio CD playback specifications
  Sampling Frequency 44.1 kHz
  Sampling Bit Rate 16 bit
Number of Channels 2
Analog audio outputs
Analog outputs (unbalanced) RCA pin jacks
  Output impedance 200 Ω
  Standard output level −10 dBV (0.32 Vrms)
  Maximum output level +6 dBV (2.0 Vrms)
Analog outputs (balanced) XLR-3-32 (1: GND, 2: HOT, 3: COLD)
  Output impedance 100 Ω
  Standard Output level +4 dBu (1.23 Vrms)
  Maximum Output level +24 dBu (12.28 Vrms)
PHONES connector 6.3-mm standard stereo jack
  Maximum output power 45 mW + 45 mW or more (THD+N 0.1% or less, 32 Ω load)
Digital audio outputs
Digital output connector (COAXIAL) RCA pin jack
  Supported signal formats IEC 60958-3 standard for consumer use,
IEC 60958-4 for professional use
  Output impedance 75 Ω
  Output level 0.5 Vpp
Digital output connector (XLR) XLR-3-32 (1: GND, 2: HOT, 3: COLD)
  Supported signal formats IEC 60958-3 standard for consumer use,
IEC 60958-4 for professional use
  Output impedance 110 Ω
Control inputs and outputs
REMOTE connector 2.5-mm TRS jack
RS-232C connector D-sub 9-pin (female)
CONTROL I/O PARALLEL D-sub 25-pin (female)
Audio performance
Frequency response 20 Hz–20 kHz ±0.5 dB (JEITA)
S/N ratio 95 dB or more (JEITA)
Dynamic range 95 dB or more (JEITA)
Distortion 0.005% or less (JEITA)
Channel separation 95 dB or more (1 kHz, JEITA)
Power supply and other specifications
Power supply AC 100-240 V, 50-60 Hz
Power consumption 12.5 W
Dimensions (W x H x D) 483 mm x 94 mm x 306 mm
Weight 4.9 kg
Operating temperature range 5–35 °C
Installation angle 15° or less

Design and specifications subject to change without notice.
